beninca control unit for 1 or 2 operators 230v brainy 9176213
Brand: BENINCA
SKU: BRAINY
€336.00 €208.32VAT INCLUDED |
|---|
beninca control unit for 1 or 2 operators 230v brainy 9176213
BENINCA - CONTROL UNIT FOR 1 OR 2 OPERATORS FOR SWING GATES, OPPOSING SLIDING GATES, HYDRAULIC OPERATORS AND INDUSTRIAL FOLDING DOORS
- INTEGRATED DISPLAY LCD
- BUILT-IN 433.92 MHZ RADIO RECEIVER 64 CODES AND 3 RADIO ENCODINGS (ADVANCED ROLLING CODE, ROLLING CODE, FIXED CODE)
- REMOVABLE TERMINAL BOARDS
- AUTOMATIC, SEMI-AUTOMATIC AND DEAD MAN OPERATION LOGIC | ENCODER INPUT FOR OBSTACLE DETECTION
- SEPARATE LIMIT SWITCH INPUTS FOR EACH MOTOR
- OPEN, CLOSE, PEDESTRIAN, STEP-BY-STEP, STOP INPUTS
- SEPARATE INPUTS FOR PHOTOCELL ACTIVE ON OPENING/CLOSING AND PHOTOCELL ACTIVE ONLY ON CLOSING
- INPUT FOR SENSITIVE EDGE N.C OR 8K2
- 230 Vac AND 12 Vac/dc ELECTRIC POWER OUTPUT
- OUTPUTS CONFIGURABLE AS GATE OPEN INDICATOR LIGHT, SERVICE LIGHT, SECOND RADIO CHANNEL OR PHOTOCELL TEST
- AUTOSET OPERATING PARAMETERS (WITH MOTORS EQUIPPED WITH ENCODER)
- SEPARATE ELECTRONIC ADJUSTMENT OF TORQUE AND WORKING TIME FOR EACH MOTOR
- ADJUSTABLE SLOWDOWNS
- POSSIBILITY OF CONFIGURING PARAMETERS AND MANAGING RADIO CONTROLS WITH ADVANTOUCH SYSTEM
- NUMBER OF OPERATIONS
- ACCESS AND PROGRAMMING PASSWORD
- MAINTENANCE WARNING
POWER SUPPLY: 230 Vac
MOTOR POWER SUPPLY: 230 Vac 600W + 600W
CONTROL UNIT
BRAINY 9176213
- INTEGRATED DISPLAY LCD
- BUILT-IN 433.92 MHZ RADIO RECEIVER 64 CODES AND 3 RADIO ENCODINGS (ADVANCED ROLLING CODE, ROLLING CODE, FIXED CODE)
- REMOVABLE TERMINAL BOARDS
- AUTOMATIC, SEMI-AUTOMATIC AND DEAD MAN OPERATION LOGIC | ENCODER INPUT FOR OBSTACLE DETECTION
- SEPARATE LIMIT SWITCH INPUTS FOR EACH MOTOR
- OPEN, CLOSE, PEDESTRIAN, STEP-BY-STEP, STOP INPUTS
- SEPARATE INPUTS FOR PHOTOCELL ACTIVE ON OPENING/CLOSING AND PHOTOCELL ACTIVE ONLY ON CLOSING
- INPUT FOR SENSITIVE EDGE N.C OR 8K2
- 230 Vac AND 12 Vac/dc ELECTRIC POWER OUTPUT
- OUTPUTS CONFIGURABLE AS GATE OPEN INDICATOR LIGHT, SERVICE LIGHT, SECOND RADIO CHANNEL OR PHOTOCELL TEST
- AUTOSET OPERATING PARAMETERS (WITH MOTORS EQUIPPED WITH ENCODER)
- SEPARATE ELECTRONIC ADJUSTMENT OF TORQUE AND WORKING TIME FOR EACH MOTOR
- ADJUSTABLE SLOWDOWNS
- POSSIBILITY OF CONFIGURING PARAMETERS AND MANAGING RADIO CONTROLS WITH ADVANTOUCH SYSTEM
- NUMBER OF OPERATIONS
- ACCESS AND PROGRAMMING PASSWORD
- MAINTENANCE WARNING
POWER SUPPLY: 230 Vac
MOTOR POWER SUPPLY: 230 Vac 600W + 600W
CONTROL UNIT
BRAINY 9176213
