came ati 230v gearmotor 001a3000a a3000a
Brand: CAME
SKU: 001A3000A
€624.00 €467.31VAT INCLUDED |
|---|
came ati 230v gearmotor 001a3000a a3000a
CAME - IRREVERSIBLE GEARMOTOR FOR SWING GATES UP TO 3 MT
- OPENING TIME 90°: 19 - 32 SECONDS
- WITH OPENING AND CLOSING LIMIT-SWITCH MICRO-SWITCHES
- CURRENT DETECTION OF THE OBSTACLE
- SOLUTION FOR RESIDENTIAL AND CONDOMINIUM APPLICATIONS
POWER SUPPLY: 230V AC
001A3000A A3000A
230V AC
| Type | A3000/A3100 A5000/A5100 | A3006/3106 A5006/A5106 | A3024N A5024N | |||
| Protection level | IP44 | |||||
| Power supply | 230V 50/60 Hz | 230V 50/60 Hz/24V D.C. | ||||
| Motor power supply | 230V 50/60 Hz | 24V D.C. | ||||
| Absorption | 1,2A | 10A max | ||||
| Nominal power | 150W | 120W | ||||
| Duty cycle | 50% | intensive duty | ||||
| Thrust | 400-3000N | |||||
| Motor's heat protection | 150°C | |||||
| Maneuvering time (90°) | 19-32s | 28-45s | adjustable | |||
| Operating temperature | -20 °C min +55 °C max | |||||
Complementary accessories (not included):
- ZA3P: Multifunctional control panel with built-in radio decoding
- LOCK81: Single cylinder electric lock
- LOCK82: Double cylinder electric lock
- D001: Lock cylinder with din key
- H3000: Case for remote release with customized key, pull-cord handle and control button. Cord length L=5m
