nice control unit for rolling shutters mc200
Brand: NICE
SKU: MC200
€79.75 |
|---|
NICE - CONTROL PANEL FOR A ROLLING SHUTTER MOTOR 230 Vac
- SIMPLIFIED PROGRAMMING VIA Pro-View OR Bidi-Wifi AND MyNice Pro App
- BUILT-IN RADIO CARD COMPATIBLE WITH SERIES TRANSMITTERS Flor AND Smilo
- POSSIBILITY OF REMOTE CONNECTION
CONTROL UNIT 230V
MC200
- SIMPLIFIED PROGRAMMING VIA Pro-View OR Bidi-Wifi AND MyNice Pro App
- BUILT-IN RADIO CARD COMPATIBLE WITH SERIES TRANSMITTERS Flor AND Smilo
- POSSIBILITY OF REMOTE CONNECTION
CONTROL UNIT 230V
MC200
TECHNICAL FEATURES:
Mains power supply (Vac 50/60 Hz) 120 / 230 ± 10%
Battery power supply (Vdc) -
Max. motor power and current (VA; A) 450 (120V) - 900 (230V); 5
Max. service current 24 V and phototest (A) 0,055
Voltage and power max. output flashing (V; W) 120 - 230; 40
Voltage and power max. output indicator AC (V; W) 24V - 1W
Working time TL (s) 5 ÷ 120
Pause time TP (s) 1 ÷ 120
Enclosure dimensions (mm) 128x112x43 h.
Mains power supply (Vac 50/60 Hz) 120 / 230 ± 10%
Battery power supply (Vdc) -
Max. motor power and current (VA; A) 450 (120V) - 900 (230V); 5
Max. service current 24 V and phototest (A) 0,055
Voltage and power max. output flashing (V; W) 120 - 230; 40
Voltage and power max. output indicator AC (V; W) 24V - 1W
Working time TL (s) 5 ÷ 120
Pause time TP (s) 1 ÷ 120
Enclosure dimensions (mm) 128x112x43 h.
